Motion Sensor IoT

Main Application

■ Presence Control System on Fitting Rooms

Possible Applications

■ Presence control in spaces
■ Lighting control through presence detection
■ Step direction detection using 3 sensors in cascade mode
■ Invisible presence control works behind wood, glass, plastic..
■ Proximity detection system
■ Barrier crossing control system



Share

Specifications


BD-IOT-SENS

X-Band Motion Sensor coompatible to BD-IOT-GTW Gateway.

Microwave motion sensor module are X-Band Mono-static DRO Doppler transceiver front-end module. These modules are designed for movement detection, like intruder alarms, occupancy modules and other innovative ideas.

This device is designed to be used as a presence sensor in spaces that require knowing in real time if they are occupied or not.
The system can indicate the status of the sensor by means of a light indicator, in addition to communicating its status to the gateway (BD-IOT-GTW) for centralized management or display.

SAMPLE PRODUCT APPLICATION (PDF)

BD-IOT-SENS

Dimensions: 124mm x67mm x35mm

Weight: G. W 80gr

Distance range: 0,5m to 3m

Input voltage: +5VDC provided by the Gateway Controller (BD-IOT-GTW)

Power Supply: BD-IOT-GTW Device (Sensor Port)

Output: RGB pwm

Central Processing Unit:

  • CPU speed: 32MHz
  • Program Memory Size: 28KB
  • RAM Memory Size: 2KB
  • Integrated Interface Type: Synchrous serial data transfer

Features


Sensitivity adjustment



The sensor allows adjustment of gain and sensitivity for motion detection by adjusting sensitivity to fast movements and slow movements.
This setting varies both the signal amplitude and the range range.


Sensor Slave Device Option

Motion detection sensors can manage another cascading device connected to them that acts as a data gateway to the main gateway (BD-IOT-GTW), like RFID Reader of the same series: BD-IOT- RDR, or other BD-IOT-SENS Sensor for double detection in larger spaces.
For example, the BD-IOT-RDR connected to the sensor as a slave allows RFID tags to be read when the BD-IOT-SENS sensor is activated by motion, sending the data to the gateway.


One Cable Interconnect

The system is designed so that, from a single centralized point where the Gateway is installed, we only have to deploy a single UTP cable to each sensor, which makes it a robust system and very easy to install.
The UTP cable itself contains data channels and power channels for the sensor.

The load is connected to the Output terminal connector in each sensor.


Output

This device, allows an output that is activated when the sensor detects presence, is used to give signal to light indicators in general, although it can be used for other purposes.

Signal output:
+ 12VDC 0.2A max shared for 3 channels (R-G-B)
This output allows powering any other device or actuator.

Rgb output:
By combining the signal output with the rgb PWM output, you can control an RGB light fixture by PWM, such as the BD-IOT-RGB same series indicator, allowing a very low power Rgb light source to indicate the activation and / or deactivation of the sensor.

It is possible to adjust the color tone, when the device does not detect movement, the color while movement is detected, and even make effects such as fade between them.

Connectivity


■ Mode Button

The mode button allows 3 functions when pressed depending on the pressing time:

  • 10s: Clean Config
  • 5s: Reset
  • 1s: Self Test

■ Sensitivity adjustment Trimmers

Adjustment trimmers allow adjusting:

Activation (the threshold for the sensor to detect movement) – Trimmer ON
Deactivation (the threshold for the sensor to deactivate after the last motion detection) – Trimmer OFF

■ Master Port to Gateway

The RJ45 connector provided to intercommunicate the sensor with the central unit (Master: BD-IOT-GTW) allows communication of both data and power from the sensor with the gateway.

■ Slave Port (Optional Slave device)

The RJ45 connector provided to intercommunicate the sensor with another similar sensor, to extend the detection range, or with another type of sensor, such as RFID (BD-IOT-RDR), allows the use of a second level of cascaded sensors.

* Only a second level of sensors is allowed, it is not possible to chain more than 2 in this way.

MQTT Protocol

MQTT

CPU

MICROCONTROLLER

X-BAND

X-Band MicroWaves
